Product Overview: Advanced Air Suspension for Modern Truck Cabins
The YSR914 represents the evolution of commercial vehicle seating, replacing traditional mechanical springs with a sophisticated airbag suspension system. This Pneumatic Truck Seats builds upon a standard platform but elevates it with premium leather upholstery and integrated climate control-both ventilation and heating functions. By substituting springs with precision‑engineered airbags, this seat delivers a noticeably smoother ride, effectively absorbing road shocks that would otherwise transfer to the driver's body. The combination of adjustable height, superior lumbar support, and precise tilt controls creates an ergonomic environment designed to promote driver well‑being, resulting in safer, more efficient operations. With these seats, commercial vehicle operators can maintain focus and comfort during extended shifts, improving both the quality of their work and the safety of everyone sharing the road.
Note: This video demonstrates the actual operation process of model YSR914-1 in this series for your reference. The operation logic for other models is similar, but specific details may differ slightly. For guidance on operating a specific model, please contact customer service.
Technical Specifications
| Product Model | YSR914 (Air Suspension Series) |
| Weight Adjustment Range | 40 – 130 kg |
| Height Adjustment Range | 65 mm |
| Backrest Adjustment Range | 80° + 41° (total 121° range) |
| Overall Dimensions (L×H×W) | 560 × 1050 × 485 mm |
| Connection Dimensions | 216 × 295.5 mm |
Key Features & Premium Components
- Superior Quality: Built with premium materials and precision manufacturing for lasting reliability.
- Exceptional Driving Experience: Air suspension technology transforms the ride, reducing fatigue and enhancing comfort.
- German‑Imported Air Spring: The heart of the suspension system is a high‑quality air spring sourced from Germany, ensuring consistent performance and longevity.
- Durable & Aesthetic Design: The leather upholstery is both durable and visually appealing, enhancing the cab environment.
- Comprehensive Warranty: Backed by a 12‑month warranty and lifetime after‑sales support.
Manufacturing Excellence: The Production Process
Every YSR914 undergoes a meticulous manufacturing process to ensure the highest quality standards:
● Stamping Process: The Pneumatic Truck Seat frame is formed from high‑strength sheet steel using precision stamping dies. Different stamping techniques are employed depending on the specific frame design, ensuring optimal structural integrity.
● Welding Process: Connections within the seat frame are primarily achieved through advanced welding techniques. We utilize state‑of‑the‑art welding equipment and strictly adhere to production specifications to guarantee weld quality and strength.
● Painting Process: Seat frames receive a protective coating through automatic electrostatic powder spraying. This method ensures uniform coverage and, after curing, provides a durable finish that resists peeling and offers excellent corrosion protection.
● Sponge Foaming: The backrest and seat cushion are created using precision sponge‑foaming processes, resulting in consistent density and long‑lasting support.
● Seat Assembly: The assembly process follows a systematic sequence:
- The frame is laid out and the slide rails are attached.
- The seat basin is connected, and the cushion and backrest assemblies are mounted.
- Carpet, baseboard, and heat insulation board are installed.
- Safety lock and backrest adjustment handles are assembled.
- Seat belt bolt torque is verified, and a final visual inspection of the seat, slide rails, and adjusters is performed.
- The finished seat is unlocked from the tooling and prepared for packaging.
● Seat Testing: Every completed seat undergoes rigorous inspection to verify the condition of all components, ensuring product quality before shipment.
Performance Advantages
The key differentiator of this air suspension seat is its adjustable height and damping system. Precision airbags can be tuned to match the driver's specific weight, height, and sitting preferences. This personalized adjustment significantly reduces fatigue, ensuring the driver remains comfortable throughout even the longest journeys.
Additionally, the precise tilting controls allow drivers to fine‑tune the seat angle to find the optimal position for their body type. This feature is particularly valuable for preventing muscle strains that can lead to chronic pain, reduced quality of life, or even early retirement from driving. By promoting proper posture and reducing physical stress, these seats contribute to a healthier, more sustainable career behind the wheel.
Production, Packaging & Global Logistics
| Category | Specification |
| Monthly Production Capacity | 800 – 1,000 units (dedicated truck seat line; scalable for large fleet orders) |
| Standard Packaging | Each seat individually packed in a heavy‑duty export carton with internal foam supports – ensures damage‑free transit. |
| Bulk / Palletized Shipments | For volume orders, seats are consolidated on fumigation‑free wooden pallets – 4, 8, or 12 units per pallet – fully stretch‑wrapped and labelled for air or sea freight. |
| Main Export Ports | Shenzhen, Guangzhou, Shanghai, Qingdao (FOB, CIF, DAP, DDP terms supported) |
| Lead Time (1‑10 pcs, standard models) | 1 – 3 business days from order confirmation (in‑stock items ready for immediate dispatch) |
| Lead Time (>10 pcs or custom orders) | Approximately 15 business days (dependent on volume and specification) |
Contact YSR Seating
Ready to experience the comfort and safety of advanced air suspension with Pneumatic Truck Seats in your truck? Contact our commercial vehicle specialists today for a quotation, technical drawings, or to discuss your requirements.
🚛 Advanced Air Suspension for Trucks – Engineered for Driver Well‑Being
Whether you need a single replacement seat or bulk quantities for fleet modernization, YSR delivers quality, value, and responsive support. Request your quote now!
